16x15mm IP68 Tunable White Neon Flex – 24V, 120 LEDs/m, CCT
Couldn't load pickup availability
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
The NE1615T-CV24-CCT is a 16 × 15 mm IP68 tunable white silicone neon flex that blends warm white and cool white channels to adjust color temperature from 2700K to 6000K. With 120 LEDs/m, CRI >90, and a vertical-bend silicone profile, it is designed for projects that need both smooth neon-style illumination and adjustable white light.
Why Choose This Neon Flex?
- 2700K–6000K tunable white: Shift from warm ambient light to clean cool white using a compatible CCT controller.
- Dual-channel 24V design: 5 W/m warm white plus 5 W/m cool white, with up to 10 W/m combined output.
- CRI >90: Better color fidelity for architectural, hospitality, retail, and residential applications.
- IP68 silicone housing: Suitable for demanding installations when paired with appropriately rated accessories.
- Vertical-bend flexibility: 16 × 15 mm profile with a 200 mm minimum bending diameter.
- 50 mm cut interval: Supports accurate custom sizing and fabrication.
Technical Specifications
| Catalog Model | NE1615T-CV24-CCT |
|---|---|
| Input Voltage | 24V DC |
| Power | 5 W/m WW + 5 W/m CW; 10 W/m combined |
| CCT Range | 2700K warm white to 6000K cool white |
| CRI | 90 |
| Product Series | NE1615 Silicone Neon Lights |
| Material | 100% food-grade silicone |
| Cross Section | 16 × 15 mm (0.63 × 0.59 in) |
| LED Density | 120 LEDs/m |
| Light Emission | 120° |
| IP Rating | IP68 with appropriately rated accessories |
| Bending Direction | Vertical bending |
| Minimum Bending Diameter | 200 mm |
| Warranty | 3 years |
| Power Feed | One-end / two-end feed |
| Cable Entry | Front |
| Humidity | 0–95% non-condensing |
| Maximum Run from One-End Feed | 5 m |
| Cut Interval | 50 mm |
Photometric Data
| Warm White 2700K | 240 lm/m · 48 lm/W |
|---|---|
| Cool White 6000K | 250 lm/m · 50 lm/W |
| CCT (WW + CW) | 490 lm/m · 49 lm/W |
Cutting and Installation
Cut only at the designated 50 mm cut marks. Connect the warm-white and cool-white channels to a compatible 24V CCT controller and power supply. Keep bends in the vertical direction and use IP68-rated accessories where waterproofing is required.
Recommended Applications
- Hospitality mood lighting with adjustable white tone
- Retail displays and architectural coves
- Residential kitchens, living spaces and feature lighting
- Commercial interiors requiring day-to-evening CCT adjustment
Accessories
Compatible accessories shown for this series include aluminum channel, mounting clips, stainless-steel flexible mounting channel, IP68 end caps, waterproof cable, and IP68 waterproof connectors. Accessories may be selected separately to match the installation.
