16x15mm IP68 Silicone Neon Flex – 24V, 120 LEDs/m, Single Color
Couldn't load pickup availability
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
The NE1615T-CV24-Wxx is a 16 × 15 mm vertical-bend silicone neon flex for architectural, commercial, and outdoor linear lighting. It operates at 24V DC with 120 LEDs/m and IP68 protection when used with appropriately rated accessories. Choose from fixed white color temperatures or saturated single colors while keeping the same compact neon profile.
Why Choose This Neon Flex?
- IP68 silicone construction: UV-resistant, saltwater-resistant, and designed for demanding indoor or outdoor installations.
- Vertical-bend 16 × 15 mm profile: Flexible in the vertical direction with a 200 mm minimum bending diameter.
- CRI >90 white-light options: 2400K, 2700K, 3000K, 4000K, and 6000K for warm through cool white applications.
- Fixed color choices: Red, Green, Blue, Yellow, and Pink options for decorative and branded lighting.
- Long one-end run: Up to 15 m from a single power feed, reducing extra feed points on long installations.
- 50 mm cut interval: Allows accurate sizing for custom runs and project fabrication.
Technical Specifications
| Catalog Model | NE1615T-CV24-Wxx |
|---|---|
| Input Voltage | 24V DC |
| Power | 10 W/m |
| CRI | 90 |
| Product Series | NE1615 Silicone Neon Lights |
| Material | 100% food-grade silicone |
| Cross Section | 16 × 15 mm (0.63 × 0.59 in) |
| LED Density | 120 LEDs/m |
| Light Emission | 120° |
| IP Rating | IP68 with appropriately rated accessories |
| Bending Direction | Vertical bending |
| Minimum Bending Diameter | 200 mm |
| Warranty | 3 years |
| Power Feed | One-end / two-end feed |
| Cable Entry | Front |
| Humidity | 0–95% non-condensing |
| Maximum Run from One-End Feed | 15 m |
| Cut Interval | 50 mm |
Photometric Data
| 2400K luminous output | 370 lm/m · 37 lm/W |
|---|---|
| 2700K luminous output | 380 lm/m · 38 lm/W |
| 3000K luminous output | 380 lm/m · 38 lm/W |
| 4000K luminous output | 410 lm/m · 41 lm/W |
| 6000K luminous output | 390 lm/m · 39 lm/W |
| Red luminous output | 170 lm/m · 17 lm/W |
| Green luminous output | 490 lm/m · 49 lm/W |
| Blue luminous output | 100 lm/m · 10 lm/W |
| Yellow luminous output | 180 lm/m · 18 lm/W |
| Pink luminous output | 440 lm/m · 44 lm/W |
Cutting and Installation
Cut only at the designated 50 mm cut marks. This profile is designed for vertical bending; do not force it into horizontal side bends. Use a compatible 24V power supply and IP68-rated end caps/connectors where environmental sealing is required.
Recommended Applications
- Architectural contour and facade lighting
- Hospitality, bars, restaurants, retail and signage
- Outdoor accents, marine-adjacent and weather-exposed installations
- Custom decorative linear lighting and neon-style features
Color Options
Available in 2400K, 2700K, 3000K, 4000K, 6000K, Red, Green, Blue, Yellow, and Pink.
Accessories
Compatible accessories shown for this series include aluminum channel, mounting clips, stainless-steel flexible mounting channel, IP68 end caps, waterproof cable, and IP68 waterproof connectors. Accessories may be selected separately to match the installation.
